Multilayer ABA Blown Film Machine
Features
- Film With High Strength & Resistance
- Fast Return on Investment
- Three layer Film
- Low Power consumpation
- Outstanding Output
Description:
This A-B-A Blown Film Extrusion Machine is basically a Blown Film Plant producing a THREE LAYER FILM but with the TWO EXTRUDER. It's a result of a specially designed A-B-A Type Co-Ex Die which enables to produce a Three Layer Film with Two Extruder. Technically in A-B-A type film, the Outer and Inner layer will be of the same Polymer as being fed by the same extruder and a Middle Layer will be of a different Polymer which will be fed by a second extruder.
The cost of virgin (raw) material (HDPE/ LDPE) continues to go up every year, and therefore many packaging film producers equipped with co-extrusion blown film extrusion machines have started to make 3 layer (A-B-A) films to reduce cost, replacing the traditional single and two layer blown film extrusion machines to stay competitive in the market.
The A-B-A Blown film extrusion lines are manufactured to adapt to a broad range of applications. The plant is a rugged and compact model - very space saving. It comes with advanced technology like the grooved Feed Technology, PID Temperature controllers, and AC Frequency Drive.
Applications:
-
APPLICATIONS OF FILM
- Garbage Bags
- Carry Bags
- Shopping Bags
- Linears
- Construction Film
- T-Shirts Bags
- Aggriculture Film
Specifications:
Model | SS ABA/35-45/600 | SS ABA/35-45/800 | SS ABA/45-55/1000 | SS ABA/55-65/1500 |
Screw Size | Extruder A-35 MM (Inner & OuterLayer) Extruder B-45 MM |
Extruder A-35 MM (Inner & OuterLayer) Extruder B-45 MM |
Extruder A-45 MM (Inner & OuterLayer) Extruder B-55 MM |
Extruder A-55 MM (Inner & OuterLayer) Extruder B-65 MM |
Layflat Width | 200 - 600 MM | 300 - 800 MM | 400 - 1000 MM | 600 - 1500 MM |
Film Thickness | 10-100 (Micron) | 20-150 (Micron) | 20-200 (Micron) | 20-200 (Micron) |
Max. Extrusion Output | 70 Kg/hr. | 85 Kg/hr. | 100 Kg/hr. | 150 Kg/hr. |
Main Motor | Extruder A-5.5KW (7.5 HP) Extruder B-11KW (15 HP) |
Extruder A-5.5 KW (7.5 HP) Extruder B-11 KW (15 HP) |
Extruder A-11 KW (15 HP) Extruder B-22.5 KW (30 HP) |
Extruder A-22.5 KW (30 HP) Extruder B-30 KW (40 HP) |
Machine Dimension (Mtrs) |
L-3.5 x W-3 x H-4.5 |
L-4 x W-3.5 x H-4.8 |
L-4.5 x W-4 x H-5 |
L-6 x W-5 x H-7 |
